PP Corrugated Sheet
Polypropylene shows a high mechanical strength and a tensile strength, but a low not ched impact strength. PP resists cracking and it is easy to weld. At minus temperature it can become brittle. The chemical and electrical properties are very good. The continuous operating temperatures range between +5 °C to +100°C.
Properties
- Low density
- High heat resistance
- High tensile strength
- High surface strength
- Very high chemical resistance
- Low oxidation resistance
- Low abrasion resistance
- Brittle in the coldness
- HF-Welding not possible
- Natural color is not weather resistance
Applications
- Pumps
- Valves
- Gaskets
- Spacer
- Supporting Stands for industries
- Tools and parts modification
- Machining assembly house
- Mechanical part for engineering and particles for toys
TEST REPORT OF PPCP
- Excellent mechanical properties.
- Good Chemical & Organic Solvent Resistance.
- Very Close Tolerance.
- Improved Wear Resistance.
- Good Impact Strength.
- Good E.S.C.R properties.
- Good Weather ability.
- Easy Mould ability Of Large Parts to Precise & Stable Dimension.
- Excellent Weld ability.
- Good Corrosion Resistance.
CHARACTERISTICS PROPERTIES
Property | Test Method | Units | Typical Value* |
---|---|---|---|
Tensile Strength @ Yield | ASTM D 638 | MPa | 26.5 |
Elongation @ Yield | ASTM D 638 | % | 11 |
Flexural Modulus | ASTM D 790 | MPa | 1000 |
Impact Strength (Izod) | ASTM D 256 | J/m | 225 |
Thickness Tolerance | D-Scale | +-5% | |
Vicat Softening Point (10N) | ASTM D1526 | °C | 150 |
HDT (0.46 N/m) | ASTM D 648 | °C | 86 |
Shore Hardness | ASTM D 648 | °C | 70 |
Regulatory Information
- Meets the requirements stipulated in IS I0910 on ‘Specification for Polypropylene and its Copolymers for safe use in contact with foodstuff, pharmaceuticals and drinking water’. Additives incorporated in this grade conform to the positive list of constituents as prescribed in IS I0909. The grade and the additive incorporated in it also comply with the FDA:CFR Title 21.177.1520, Olefin polymers.
- The above values are the general properties as per the manufacturer’s specifications and are presumed to be true as per standard practice. We do not endorse the above values. Tecafine Polymer Pvt Ltd is indemnified from any or all liabilities and does not make any guarantees. This is for your reference and records.
Sampling:
The sizes of the samples are approx A4 but sizes may vary slightly depending on availability.
Delivery:
Orders are delivered via a next day service and we aim to dispatch all orders within 48 hrs, 80% of our orders are currently being delivered within 3 working days from ordering. However during busy periods, or if the product is out of stock, we may dispatch within three to four working days from when we receive your order.
Track Order Status:
We pride ourselves on great customer service and communication – during the order process you will receive several emails to keep you up to date with the status of your order and also when it has been dispatched.
Packing:
All sizes of this product are dispatched with protective bubble sheet and Woven sacks on both side.
Dispatch information:
We have an excellent relationship with our Transporter service and all orders are meticulously packed using a variety of materials to ensure the sheets arrive in excellent condition.
Please Note:
Our current machines work to a tolerance Thickness of +/- 0.1mm. Colour of sheets may differ slightly due to variance in computer monitors.
PP CORRUGATE SHEET DETAILS
Sr | Thickness | Width | Length | GSM | Colour | Packing | |||||
---|---|---|---|---|---|---|---|---|---|---|---|
1 | 2 MM | 1.22 Meter | 2.44 Meter | 250 GSM to 600 GSM | Natural | White | I.Grey | Blue | Black | Yellow | 75 Sheets |
2 | 2.5 MM | 1.22 Meter | 2.44 Meter | 300 GSM to 750 GSM | Natural | White | I.Grey | Blue | Black | Yellow | 60 Sheets |
3 | 3 MM | 1.22 Meter | 2.44 Meter | 350 GSM to 900 GSM | Natural | White | I.Grey | Blue | Black | Yellow | 50 Sheets |
4 | 3.5 MM | 1.22 Meter | 2.44 Meter | 400 GSM to 1000 GSM | Natural | White | I.Grey | Blue | Black | Yellow | 45 Sheets |
5 | 4 MM | 1.22 Meter | 2.44 Meter | 550 GSM to 1100 GSM | Natural | White | I.Grey | Blue | Black | Yellow | 40 Sheets |
6 | 4.5 MM | 1.22 Meter | 2.44 Meter | 600 GSM to 1200 GSM | Natural | White | I.Grey | Blue | Black | Yellow | 35 Sheets |
7 | 5 MM | 1.22 Meter | 2.44 Meter | 650 GSM to 1300 GSM | Natural | White | I.Grey | Blue | Black | Yellow | 30 Sheets |
8 | 6 MM | 1.22 Meter | 2.44 Meter | 900 GSM to 1450 GSM | Natural | White | I.Grey | Blue | Black | Yellow | 25 Sheets |
9 | 7 MM | 1.22 Meter | 2.44 Meter | 1200 GSM to 1600 GSM | Natural | White | I.Grey | Blue | Black | Yellow | 20 Sheets |
10 | 8 MM | 1.22 Meter | 2.44 Meter | 1600 GSM to 2100 GSM | Natural | White | I.Grey | Blue | Black | Yellow | 10 Sheets |
