HDPE
Polyethylene has a good chemical resistance to almost all acids, lyes, many organic solvent and hot water.HDPE has good insulation properties and its easy to weld. The operating temperature is from -50 °C to 90+ °C.
Properties
- High Density
- High Toughness
- High elongation at break
- Very good electrical and dielectric properties
- Very low water absorption
- Low steam permeability
- Good protection against stress cracking
- Food safe
- Soft surface
- Natural color is not weather resistant
Applications
- Transport Containers
- Pumps
- Valves Parts
- Parts in the Tank Construction
- Components with medical applications
- Gaskets
- Spacer
- Sliding Profiles
- Components For Food
- Textiles
- Food
- Printing
- Packaging
- Auto mobile
- Chemical
- Pharmacy
- Mine
- Electroplating Plants
- Galvanizing Plants
- Pickling Plants
- Lining Work
- Surface Treatment Plants
- Sewage Plant
- Construction and Automobile & Engineering Parts Industries
TEST REPORT OF HDPE
Property | Test Method | Units | Value |
---|---|---|---|
Density (at 23°C) | ASTM D 1505 | g/cm | 0.950 |
Physical Property | |||
Tensile Strength at Yield** | MPa | 21 | |
Tensile Strength at Break** | ASTM D 638 | MPa | 35 |
Elongation at Break** | % | >1000 | |
Izod Impact Strength (Notched, | ASTM D 256 | J/m | >500 |
Flexural Modulus | ASTM D 790 | MPa | 850 |
Hardness | ASTM D 2240 | Shore D | 65 |
DSC Melting Temperature | ASTM D 2117 | C | 131 |
** Tensile Properties are on Compression Molded Type IV Specimens as per ASTM D 638.
The above values are the general properties as per the manufacturer’s specifications and are presumed To be true as per standard practice. We do not endorse the above values. Tecafine Polymer Pvt Ltd is Indemnified from any or all liabilities and does not make any guarantees.
This is for your reference and records please.
Sampling:
The sizes of the samples are approx A4 but sizes may vary slightly depending on availability.
Delivery:
Orders are delivered via a next day service and we aim to dispatch all orders within 48 hrs, 80% of our orders are currently being delivered within 3 working days from ordering. However during busy periods, or if the product is out of stock, we may dispatch within three to four working days from when we receive your order.
Track Order Status:
We pride ourselves on great customer service and communication – during the order process you will receive several emails to keep you up to date with the status of your order and also when it has been dispatched.
Packing:
All sizes of this product are dispatched with protective bubble sheet and Woven sacks on both side.
Dispatch information:
We have an excellent relationship with our Transporter service and all orders are meticulously packed using a variety of materials to ensure the sheets arrive in excellent condition.
Please Note:
Our current machines work to a tolerance Thickness of +/- 0.1mm. Colour of sheets may differ slightly due to variance in computer monitors.
HDPE SHEET DETAILS
Sr | Thickness | Width | Length | Weight Per Sheet | Colour | Packing | |||||
---|---|---|---|---|---|---|---|---|---|---|---|
1 | 1 MM | 1.22 Meter | 2.44 Meter | 2.9 KG. | Natural | White | I.Grey | Blue | Black | Yellow | 20 Sheets |
2 | 2 MM | 1.22 Meter | 2.44 Meter | 5.7 KG. | Natural | White | I.Grey | Blue | Black | Yellow | 10 Sheets |
3 | 3 MM | 1.22 Meter | 2.44 Meter | 8.6 KG. | Natural | White | I.Grey | Blue | Black | Yellow | 10 Sheets |
4 | 4 MM | 1.22 Meter | 2.44 Meter | 11.4 KG. | Natural | White | I.Grey | Blue | Black | Yellow | 10 Sheets |
5 | 5 MM | 1.22 Meter | 2.44 Meter | 14.3 KG. | Natural | White | I.Grey | Blue | Black | Yellow | 5 Sheets |
6 | 6 MM | 1.22 Meter | 2.44 Meter | 17.1 KG. | Natural | White | I.Grey | Blue | Black | Yellow | 5 Sheets |
7 | 8 MM | 1.22 Meter | 2.44 Meter | 22.9 KG. | Natural | White | I.Grey | Blue | Black | Yellow | 4 Sheets |
8 | 10 MM | 1.22 Meter | 2.44 Meter | 28.6 KG. | Natural | White | I.Grey | Blue | Black | Yellow | 3 Sheets |
9 | 12 MM | 1.22 Meter | 2.44 Meter | 34.3 KG. | Natural | White | I.Grey | Blue | Black | Yellow | 2 Sheets |
10 | 15 MM | 1.22 Meter | 2.44 Meter | 42.9 KG. | Natural | White | I.Grey | Blue | Black | Yellow | 2 Sheets |
11 | 18 MM | 1.22 Meter | 2.44 Meter | 51.4 KG. | Natural | White | I.Grey | Blue | Black | Yellow | 1 Sheets |
12 | 20 MM | 1.22 Meter | 2.44 Meter | 57.2 KG. | Natural | White | I.Grey | Blue | Black | Yellow | 1 Sheets |
13 | 25 MM | 1.22 Meter | 2.44 Meter | 71.4 KG | Natural | White | I.Grey | Blue | Black | Yellow | 1 Sheets |
14 | 30 MM | 1.22 Meter | 2.44 Meter | 85.7 KG. | Natural | White | I.Grey | Blue | Black | Yellow | 1 Sheets |
15 | 35 MM | 1.2 Meter | 2 Meter | 84 KG. | Natural | White | I.Grey | Blue | Black | Yellow | 1 Sheets |
16 | 40 MM | 1.2 Meter | 2 Meter | 96 KG. | Natural | White | I.Grey | Blue | Black | Yellow | 1 Sheets |
17 | 50 MM | 1.2 Meter | 2 Meter | 120 KG. | Natural | White | I.Grey | Blue | Black | Yellow | 1 Sheets |
18 | 65 MM | 1.2 Meter | 2 Meter | 156 KG. | Natural | White | I.Grey | Blue | Black | Yellow | 1 Sheets |
19 | 75 MM | 1.2 Meter | 2 Meter | 180 KG. | Natural | White | I.Grey | Blue | Black | Yellow | 1 Sheets |
20 | 100 MM | 1.2 Meter | 2 Meter | 240 KG. | Natural | White | I.Grey | Blue | Black | Yellow | 1 Sheets |
